Single-Core Cable Splitter – Advanced Branch Connection Solution
Xi'an OUKAMU Power Technology presents the Model D-JFZ-300/50 Single-Core Cable Splitter, engineered with 20 years of specialization in branch cable joint technology. This new connector works with main cables that are between 240mm and 300mm in size, and branch cables that range from 6mm to 50mm.It is rated for 0.6/1kV.The connector is built to be insulated, resistant to flames, able to withstand fire, and waterproof.It can be reused, so you don't need to cut the main cables or keep extra lengths ready.It allows for easy placement during installation, saving 2 to 3 meters of cable for each connection.This helps lower the cost of materials, labor, and the time needed for installation.It also follows the GB/T 14048.7-2016 standard and meets international safety requirements.
What Makes This Single-Core Cable Splitter Different?
Your infrastructure projects demand reliable, cost-effective solutions. Traditional cable branching methods require cutting main lines, reserving excess cable length, and extensive labor hours. Our patented technology changes everything.
The D-JFZ-300/50 connector represents a breakthrough in cable T-connection systems. You can create secure branch connections without interrupting the main power line. This means no service disruption during installation and maintenance.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Model | D-JFZ-300/50 |
| Main Cable Range | 240mm～300mm |
| Branch Cable Range | 6mm～50mm |
| Rated Voltage | 0.6/1kV |
| Compliance Standards | GB/T 14048.7-2016, International Safety Standards |
| Protection Features | Insulated, Flame Retardant, Fire Resistant, Waterproof |
| Reusability | Yes |
| Cable Savings | 2-3 meters per connection |
| Installation Method | No main cable cutting required |
Product Selection
| Product Name | Model Number | Specifications | Unit | |
| Range of Cross-Sectional Areas for Main Cables | Range of Cross-Sectional Areas for Branch Cables | |||
| Single-Core Integrated Splitter | D-JFZ-50/35 | 10～50 | 6～35 | Set |
| Single-Core Integrated Splitter | D-JFZ-95/50 | 50～95 | 6～50 | Set |
| Single-Core Integrated Splitter | D-JFZ-185/35 | 120～185 | 6～35 | Set |
| Single-Core Integrated Splitter | D-JFZ-185/70 | 70～185 | 50～70 | Set |
| Single-Core Integrated Splitter | D-JFZ-185/95 | 70～185 | 70～95 | Set |
| Single-Core Integrated Splitter | D-JFZ-300/50 | 240～300 | 6～50 | Set |
| Single-Core Integrated Splitter | D-JFZ-300/95 | 240～300 | 70～95 | Set |
| Single-Core Integrated Splitter | D-JFZ-300/185 | 120～300 | 120～185 | Set |
| Single-Core Integrated Splitter | D-JFZ-500/50 | 400～500 | 6～50 | Set |
| Single-Core Integrated Splitter | D-JFZ-500/95 | 400～500 | 70～95 | Set |
| Single-Core Integrated Splitter | D-JFZ-500/150 | 400～500 | 120～150 | Set |
| Single-Core Integrated Splitter | D-JFZ-500/240 | 240～500 | 185～240 | Set |
| Single-Core Integrated Splitter | D-JFZ-630/50 | 630 | 6～50 | Set |
| Single-Core Integrated Splitter | D-JFZ-630/95 | 630 | 70～95 | Set |
| Single-Core Integrated Splitter | D-JFZ-630/150 | 630 | 120～150 | Set |
| Single-Core Integrated Splitter | D-JFZ-630/240 | 630 | 185～240 | Set |
| Single-Core Integrated Splitter | D-JFZ-630/400 | 300～400 | 300～400 | Set |
Superior Performance FeaturesEffortless Installation Process
You'll appreciate how simple installation becomes. The connector attaches directly to your existing main cable without cutting. No specialized tools beyond standard electrical equipment are needed.
Your installation team can complete connections on-site in minutes rather than hours. This reduces project timelines and labor costs significantly. The flexible positioning allows adaptation to various spatial constraints you encounter in real-world applications.
Integrated Safety Design
Safety remains paramount in electrical systems. The integrated design encases both main and branch cable connections within a flame-retardant, fire-resistant insulated body. This comprehensive protection ensures your installation meets the strictest safety requirements.
The Single-Core Cable Splitter provides multiple layers of protection:
- Complete insulation against electrical leakage
- Flame retardant materials preventing fire propagation
- Fire-resistant construction for extreme conditions
- Waterproof sealing for outdoor and underground installations
- Dustproof barriers extending service life
- Anti-aging compounds maintaining performance over decades
Compact and Versatile Structure
Space constraints challenge many projects. This connector's compact design fits into cable bridges, conduits, and open installations with equal ease. You gain installation flexibility without compromising connection quality.
The small footprint reduces building space requirements. Whether you're working on high-rise construction, underground metro systems, or highway infrastructure, this solution adapts to your environment.
Economic Advantages You'll Notice
Significant Cost Savings
Every connection saves you 2-3 meters of main cable. Multiply this across dozens or hundreds of branch points in your project, and the savings become substantial.
You'll also reduce:
- Labor hours by 40-60% compared to traditional methods
- Installation equipment needs
- Temporary power interruption costs
- Future maintenance expenses
Reusable Technology
Unlike one-time-use connectors, this Single-Core Cable Splitter can be removed and reinstalled. When you need to modify your electrical distribution layout, simply reposition the connector. This reusability provides long-term value beyond initial installation.
Durability in Demanding Environments
Your projects face harsh conditions. Our connector withstands:
- Extreme temperatures from -40°C to +85°C
- High humidity and direct water exposure
- UV radiation in outdoor installations
- Electrochemical corrosion in industrial settings
- Mechanical vibration from traffic and equipment
The anti-aging materials maintain electrical and mechanical properties for 30+ years of service life. You won't face premature replacement costs that plague inferior products.
Applications Across Infrastructure Sectors
This technology has proven itself in over 10,000 major projects, including:
- Transportation Infrastructure: High-speed railways, metro systems, highways
- Commercial Buildings: Office towers, shopping centers, hotels
- Public Facilities: Hospitals, sports centers, educational institutions
- Municipal Engineering: Street lighting, traffic systems, public utilities
- Industrial Plants: Manufacturing facilities, power distribution networks
Technical Innovation Backed by Patents
Xi'an OUKAMU holds over 150 national invention patents. Our cable branch connection technology enjoys 20-year patent protection, representing genuine innovation rather than copied designs.
You benefit from continuous R&D investment. Our engineering team constantly refines connection systems based on real-world feedback from projects like yours.
Installation Flexibility You Need
Traditional cable joints force you to plan branch points during initial installation. Our system provides flexibility throughout your project lifecycle:
- Add branch connections after main cable installation
- Modify distribution layouts without replacing main lines
- Expand systems as building requirements grow
- Relocate branch points during renovations
This adaptability future-proofs your electrical infrastructure.
Frequently Asked Questions
Q: Can I install this product without cutting the main power cable?
A: Yes, absolutely. The patented design allows direct clamping onto the main cable without cutting. This maintains power continuity and preserves cable integrity, which is one of the core advantages of our technology.
Q: What cable sizes are compatible with the D-JFZ-300/50 model?
A: This model accommodates main cables from 240mm to 300mm in cross-section and branch cables from 6mm to 50mm. If your project requires different specifications, we offer additional models covering wider ranges.
Q: How does this connector perform in outdoor or underground installations?
A: The waterproof, dustproof design makes it ideal for harsh environments. The flame-retardant and fire-resistant materials meet safety standards for both exposed outdoor installations and enclosed underground conduits. It resists moisture, temperature extremes, and electrochemical corrosion.
Q: Is the connector reusable if I need to relocate or modify the branch connection?
A: Yes, the advanced design allows removal and reinstallation without damaging the connector or cables. This reusability provides flexibility for future modifications and reduces long-term costs.
Q: What certifications does this product hold?
A: The D-JFZ-300/50 complies with GB/T 14048.7-2016 Chinese national standards and international safety standards. Our manufacturing facility maintains strict quality control backed by Xi'an OUKAMU's 150+ patents in cable connection technology.
Q: How much installation time can I save compared to traditional methods?
A: Most installations complete in under 30 minutes per connection point, compared to 2-3 hours for traditional cut-and-splice methods. You'll also eliminate the need for main cable length reservations, streamlining your entire cable routing plan.
Q: What is the expected service life of this connector?
A: With proper installation, the anti-aging materials and robust construction provide 30+ years of reliable service. The fire-resistant and corrosion-resistant properties maintain performance throughout the product lifecycle.
Q: Can this be used in projects requiring high safety standards like hospitals or public transportation?
A: Absolutely. Our products have been successfully deployed in major infrastructure projects including metro systems, high-speed railways, Olympic facilities, and medical centers. The comprehensive safety features meet stringent requirements for critical applications.
